2.4G controller-AP-1201/RGB


Model:  AP-1201

Color:  white

Material:  PVC


Product Features

The 2.4G-RGB controller adopts the current advanced PWM (pulse width modulation) control technology; With 640,000 colors and 15 presentation modes to choose from, and with memory function, it is widely used in lighting control of RGB LED strips, light strips and other products. The working voltage DC1224V is universal, the maximum load current of each channel is 6A, and the remote control distance is 20~30 meters. Radio 2.4G (2400-2483.5MHz), stronger anti-interference, higher stability and so on; Worldwide, the remote control uses 2 batteries.

2.4G controller



Model

AP-1201

AP-1202

AP-1202-1

AP-1203

Type

RGB

RGBW

RGBW(white)

RGBWC

Output current

Max 18A

Max 24A

Max 24A

Max 30A


INPUT

12-24V









RF

2.4G



PARAMETERS

SIZE/CM

G.W./KG

TEMPE RATURE

-20~60



1PCS

11.3*13*2.8

0.11

DIST ANCE

20M



100PCS

66*29*27

12
